Progressive Headers
Coldformers

CS 520

For highest productivity in cold forming.

With the 5-station Progressive Header CS 520 parts with extremely complex shapes which have special requirements for shapes, features and tolerances can be produced with wire diameter up to 20 mm at rates of up to 140 parts per minute.

The press is also available in the CS 520 WS version, which is equipped with a pre-heating induction system to allow the use of material like titanium and super alloys, that required pre-heating to be formed.

icon
5-stations
Coldformer
icon
20 mm
Max. wire diameter
icon
140 parts
Output per minute
icon
2250 kN
Max. heading tonnage

Carlo Salvi Progressive Headers CS 520

Benefit from the following advantages

  • For components with extremely complex shapes
  • For components with special requirements on shape, features and tolerances
  • For special screws, bolts, solid, semi-tubular and fully tubular components
  • Trimming station on last two stations

Technical specifications

to all Progressive Headers

Progressive Headers Model series

CS 520

5

195

40

160

14 – 20

140

2250

110 x 180

80 x 165

48

CS 520 WS

5

195

40

160

14 – 20

14 – 19.5

140

2250

110 x 180

80 x 165

48

CS 663 LF

6

35

8

25

1,2 – 4

400

150

34 x 40

22 x 72

10

CS 663 E

6

35

8

30

2 – 5

400

150

34 x 40

22 x 72

15

CS 667

6

75

17

65

3 – 8

250

550

50 x 130

40 x 105

22

CS 558

5

90

20

80

4 – 12

250

800

60 x 95

50 x 115

30

CS 558 WS

5

90

20

80

4 – 12

250

800

60 x 95

50 x 115

30

CS 668

6

90

20

80

4 – 12

250

800

60 x 95

50 x 115

30

CS 668 WS

6

90

20

80

4 – 12

4 – 10

250

800

60 x 95

50 x 115

30

CS 513

5

135

28

100

6 – 12

180

1050

70 x 130

60 x 120

30

CS 513 WS

5

135

28

100

6 – 12

6 – 11

180

1050

70 x 130

60 x 120

30

CS 613

6

135

28

100

6 – 12

180

1050

70 x 130

60 x 120

30

CS 613 WS

6

135

28

100

6 – 12

6 – 11

180

1050

70 x 130

60 x 120

30

CS 516

5

160

35

130

10 – 16

160

1550

90 x 150

70 x 140

40

CS 516 WS

5

160

35

130

10 – 16

10 – 15

160

1550

90 x 150

70 x 140

40

CS 616

6

160

35

130

10 – 16

160

1550

90 x 150

70 x 140

40

CS 616 WS

6

160

35

130

10 – 16

10 – 15

160

1550

90 x 150

70 x 140

40

CS 620

6

195

40

160

14 – 20

140

2250

110 x 180

80 x 165

48

CS 620 WS

6

195

40

160

14 – 20

16 – 19.5

140

2250

110 x 180

80 x 165

48

* Max speed of production depends on shape of parts, on material employed, on wire strength, on cutting and heading tonnage and on tools dimensions.

WS = warm series
